NoisKen ESS-2000AX靜電放電發(fā)生器器
型 號：ESS-2000/TC-815P（選購件）
品 牌：日本 NoisKen
ESS-2000在接觸和空氣放電模式下均產生30kV的放電脈沖。它滿足IEC61000-4-2標準，主機有一塊5英寸的LCD顯示屏、數(shù)字輸入鍵、一個很輕的放電槍和GP-IB接口。配合多種電容和電阻放電單元，可方便地在槍內更換，可編程操作提供了四種試驗模式。
圖中放電支架是可選件
輸出電壓：0.2kV~30kV
極性：正或負
上升沿：0.7~1ns
放電模式：接觸放電或氣隙放電
放電電容：150pF
放電電阻：330Ω
操作模式：手動、IEC（預置4個試驗等級）、掃描（自動電壓漸升）及程序控制
有各種選件可供選擇：溫度和濕度傳感器、自動靜電消除器等
更換電阻和電容后可滿足各種汽車電器的靜電試驗
GENERAL
The ESS-2000AX ESD Simulator generates highly consistent, repeatable ESD pulses up to 30kV in both contact and air discharge modes. Compliant with IEC61000-4-2 standard, the unit features a 5.7-inch display, a lightweight gun and optic serial interface.
A variety of capacitor and resistor units are available and are easily changeable within the gun. The fully- programmable, menu-driven simulator offers three trigger modes.
FEATURES
Fully programmable menu-driven simulator providing three operation modes: IEC standard, Manual and Sequence
A 5.7-inch color LCD for easy setting and good visibility
Unique shape for the operator's easy access to the control and displays even when the unit is put on the floor level (ground plane)
Communications with PC through the optic serial interface
A wide variety of the dedicated options
SPECIFICATIONS
|
| Output polarity | Positive or negative |
| Output voltage | 0.20kV~30.0kV ±5% (30.5kV max)
0.20kV~10.0kV: 0.01V step, 10.0kV~30.0kV:0.1V step |
| Discharge interval | Normal mode: 0.05s~600.0s ±10%
Extra mode : 1.00s~600.0s ±10%
0.05s~9.99s: 0.01s step, 10s~600.0s: 0.1s step |
| No. of times of discharge | 1~60,000 times preset on the counter or continuous |
| Discharge mode | Air/contact discharge |
| Radiation level | Normal/Extra mode |
| Trigger mode | Gun trigger/main unit trigger/ external trigger |
Operation
mode | IEC standard | Contact discharge: 2.0kV, 4.0kV, 6.0kV, 8.0kV
(4 voltages preset)
Air discharge: 2.0kV, 4.0kV, 8.0kV, 15.0kV (4 voltages preset) |
| Manual | Contact/Air discharge: 0.20kV～30.0kV
Sweep (automatic voltage ramping) available
Up to 99 units (test settings) storable |
| Sequence | Seamless run of the selected test sequence (made of any combination of 99 units in Manual mode)
No. of units per one test sequence: up to 30 units
No. of test sequences: up to 20 |
| Warning lamp | Lights up while the HV circuitry is on
Blinks while discharges are in progress |
| Discharge gun | TC-815R |
| Charging resistance | 10M ohm(53 M ohm for combination with TC-815R discharge gun) |
| AUX connector | D-SUB15 pin, female connector
Warning lamp (optional) connection
Automatic ESD Eliminator (optional) connection
External interlock input
External trigger input |
| Optical communication connector | Optic RS-232C for PC communication |
| Power supply | 100~240V AC 50/60 Hz ±10% |
| Power consumption | 75VA |
| Operating temperature and humidity | +15~+35oC, 25~75% (no condensation) |
| Character display | English, Chinese, Korean, Japanese |
| Dimensions and weight | 260 (W) X 230 (H) X 285 (D) mm (projection excluded) |
